Specifications:
Input 24 Bit 96kHz USB stream (maximum)
Output impedance 50Ω SPDIF stream
Power requirement 5V DC 160mA max (Drawn from host computer’s USB socket)
Connections
Digital input (USB) 1 USB type B
Digital outputs (SPDIF) 1 RCA socket (coaxial)
1 TOSLINK (optical)
Dimensions
Length 170mm 6⅔” including terminals
Width 95mm 3¾”
Height 40mm 1⅔” including “feet”
Weight
Unit alone 350g 12¼ oz
Unit packed in carton 400g 14 ¼ oz
|
