Specifications:
Up sampling 24 Bit 192kHz
Output impedance 47Ω
Maximum output 2.2V
Total harmonic distortion 0.004% 20Hz-20kHz
Frequency response +0, -0.1dB 20Hz-20kHz
Crosstalk -104dB 20Hz-20kHz
Signal / noise ratio -117dB “A”-weighted
Total Jitter 12ps
Power requirement 12V DC 500mA
USB input Asynchronous data stream at up to 24-bit/96kHz sampling
Connections
Digital inputs 1 RCA (coaxial), 1 TOSLINK (optical), 1 USB (type B)
Line level outputs 1 pair RCA sockets
Power input 1.3mm DC power socket
Dimensions
Length 170mm 6⅔” including terminals
Width 95mm 3¾”
Height 42mm 1⅔”
Weight Unit alone 350g
Unit packed in carton 1Kg
Accessories DC power supply 12V 500mA 1 off
( supplied ) Leaflet V-DAC instructions 1 off |
