Specifications : Power 0.25W /channel into 32 Ohms
Output devices 2 per channel
Output impedance 5Ω
Total harmonic distortion <0.005% typical 20Hz-20 kHz
Signal/noise ratio >109dB ‘A’ weighted
Input impedance 25 KΩ
Frequency response +0, -1dB 20Hz to 80 kHz
Power requirement: 12V DC 500mA
Connections : Line level inputs: 1 pair line level RCA connectors,
Line level outputs: 1 pair RCA [connected to inputs as loop through]
Headphone outputs 1 Stereo Jack socket 6.35mm, ¼”
1 Stereo Jack socket 3.5mm, ⅛”
Power input 1.3mm DC power socket
Dimensions: Length 180mm 7” including terminals and volume
Width 95mm 3 ¾”
Height 40mm 1 ⅔” including “feet”
Weight: Unit alone 350g 12¼oz
Total packed carton 1Kg 2 ¼lbs
Accessories Power Supply Unit 12V DC 500mA 1 off
(supplied) Leaflet V-CANII Instructions 1 off
|
